Description

Each Haynes manual is written for the do-it-yourselfer and provides step-by-step instructions based on a complete disassembly of the vehicle. This hands-on experience provides the reader with specific and detailed instructions for performing everything from basic maintenance and troubleshooting to a complete engine overhaul. The models and model years covered in this title are as follows:

Jeep Patriot (07-17)
Jeep Compass (07-17)
Exclusions: Does not include information specfic to diesel models

This Haynes automotive repair manual includes 700+ photos and the following chapters:

Introduction
Chapter 1: Tune-up and routine maintenance
Chapter 2: Part A: Engines
Chapter 2: Part B: General engine overhaul procedures
Chapter 3: Cooling, heating and air conditioning systems
Chapter 4: Fuel and exhaust systems
Chapter 5: Engine electrical systems
Chapter 6: Emissions control systems
Chapter 7: Part A: Manual transaxle
Chapter 7: Part B: Automatic transaxle
Chapter 7: Part C: Transfer case
Chapter 8: Clutch and drivetrain
Chapter 9: Brakes
Chapter 10: Suspension
Chapter 11: Body
Chapter 12: Chassis electrical system
Wiring Diagrams
